A6CE: Graphics - Demon
For information on this creature, see Creatures: Demon
demon graphics animation
Demon concept art - original sketch
Demon original concept art ( from Hewson founder) Click image for a larger version
A6CE DEFB %10000011 Graphic properties
DEMON - FRAME 1
demon animation frame 1
A6CF DEFB $07 Graphic consists of 7 tiles
Demon - frame 1 - tile 1
A6D0 DEFB $E4 Horizontal (X axis) pixel offset (-28 pixels)
A6D1 DEFB $F9 Vertical (Y axis) pixel offset (-7 pixels)
A6D2 DEFB $02 Graphic consists of 2 bytes
A6D3 DEFB $1F,$27 demon-1
Demon - frame 1 - tile 2
A6D5 DEFB $EC Horizontal (X axis) pixel offset (-20 pixels)
A6D6 DEFB $F9 Vertical (Y axis) pixel offset (-7 pixels)
A6D7 DEFB $0A Graphic consists of 10 bytes
A6D8 DEFB $C0,$F8,$FF,$7C,$3F,$1E,$1D,$0B demon-2
A6E0 DEFB $0F,$0F
Demon - frame 1 - tile 3
A6E2 DEFB $F4 Horizontal (X axis) pixel offset (-12 pixels)
A6E3 DEFB $FB Vertical (Y axis) pixel offset (-5 pixels)
A6E4 DEFB $15 Graphic consists of 21 bytes
A6E5 DEFB $E0,$7F,$3F,$CF,$F1,$FE,$FE,$FD demon-3
A6ED DEFB $7B,$27,$3F,$07,$03,$01,$01,$03
A6F5 DEFB $02,$02,$02,$01,$01
Demon - frame 1 - tile 4
A6FA DEFB $FC Horizontal (X axis) pixel offset (-4 pixels)
A6FB DEFB $F2 Vertical (Y axis) pixel offset (-14 pixels)
A6FC DEFB $1F Graphic consists of 31 bytes
A6FD DEFB $81,$9D,$FF,$77,$00,$63,$55,$00 demon-4
A705 DEFB $00,$22,$3E,$FF,$FF,$FF,$B7,$C9
A70D DEFB $77,$6B,$BE,$B2,$BF,$FF,$6B,$4B
A715 DEFB $53,$97,$A6,$64,$32,$32,$9A
Demon - frame 1 - tile 5
A71C DEFB $04 Horizontal (X axis) pixel offset (+4 pixels)
A71D DEFB $FA Vertical (Y axis) pixel offset (-6 pixels)
A71E DEFB $17 Graphic consists of 23 bytes
A71F DEFB $03,$07,$1C,$FB,$F7,$9F,$5F,$BF demon-5
A727 DEFB $5F,$6F,$F6,$FE,$F8,$F8,$70,$60
A72F DEFB $40,$40,$A0,$A0,$A0,$A0,$A0
Demon - frame 1 - tile 6
A736 DEFB $0C Horizontal (X axis) pixel offset (+12 pixels)
A737 DEFB $FA Vertical (Y axis) pixel offset (-6 pixels)
A738 DEFB $09 Graphic consists of 9 bytes
A739 DEFB $FF,$F3,$0E,$FC,$78,$B0,$D0,$F0 demon-6
A741 DEFB $80
Demon - frame 1 - tile 7
A742 DEFB $14 Horizontal (X axis) pixel offset (+20 pixels)
A743 DEFB $F9 Vertical (Y axis) pixel offset (-7 pixels)
A744 DEFB $03 Graphic consists of 3 bytes
A745 DEFB $70,$EC,$80 demon-7
DEMON - FRAME 2
demon animation frame 2
A748 DEFB $05 Graphic consists of 5 tiles
Demon - frame 2 - tile 1
A749 DEFB $EC Horizontal (X axis) pixel offset (-20 pixels)
A74A DEFB $F3 Vertical (Y axis) pixel offset (-13 pixels)
A74B DEFB $0D Graphic consists of 13 bytes
A74C DEFB $78,$9C,$0F,$07,$05,$07,$03,$03 demon-8
A754 DEFB $03,$03,$03,$02,$01
Demon - frame 2 - tile 2
A759 DEFB $F4 Horizontal (X axis) pixel offset (-12 pixels)
A75A DEFB $F5 Vertical (Y axis) pixel offset (-11 pixels)
A75B DEFB $11 Graphic consists of 17 bytes
A75C DEFB $80,$E0,$78,$BC,$DC,$EE,$E3,$DD demon-9
A764 DEFB $7E,$FE,$FD,$3B,$17,$0F,$07,$03
A76C DEFB $01
Demon - frame 2 - tile 3
A76D DEFB $FC Horizontal (X axis) pixel offset (-4 pixels)
A76E DEFB $F1 Vertical (Y axis) pixel offset (-15 pixels)
A76F DEFB $22 Graphic consists of 34 bytes
A770 DEFB $80,$80,$9C,$FF,$77,$00,$63,$36 demon-10
A778 DEFB $00,$00,$22,$44,$BE,$7F,$BE,$B6
A780 DEFB $49,$77,$89,$BE,$BD,$12,$01,$70
A788 DEFB $70,$40,$44,$84,$8C,$89,$C9,$CD
A790 DEFB $6D,$7D
Demon - frame 2 - tile 4
A792 DEFB $04 Horizontal (X axis) pixel offset (+4 pixels)
A793 DEFB $F1 Vertical (Y axis) pixel offset (-15 pixels)
A794 DEFB $22 Graphic consists of 34 bytes
A795 DEFB $80,$80,$80,$80,$00,$01,$07,$1D demon-11
A79D DEFB $1B,$20,$6F,$DF,$BF,$7F,$FF,$9F
A7A5 DEFB $E1,$7F,$7E,$F8,$F0,$E0,$B0,$78
A7AD DEFB $E8,$D0,$B8,$A8,$48,$50,$D0,$D0
A7B5 DEFB $50,$50
Demon - frame 2 - tile 5
A7B7 DEFB $0C Horizontal (X axis) pixel offset (+12 pixels)
A7B8 DEFB $F3 Vertical (Y axis) pixel offset (-13 pixels)
A7B9 DEFB $0C Graphic consists of 12 bytes
A7BA DEFB $0F,$38,$50,$A0,$60,$E0,$E0,$E0 demon-12
A7C2 DEFB $20,$F0,$C0,$80
DEMON - FRAME 3
demon animation frame 3
A7C6 DEFB $04 Graphic consists of 4 tiles
Demon - frame 3 - tile 1
A7C7 DEFB $ED Horizontal (X axis) pixel offset (-19 pixels)
A7C8 DEFB $F7 Vertical (Y axis) pixel offset (-9 pixels)
A7C9 DEFB $04 Graphic consists of 4 bytes
A7CA DEFB $01,$03,$04,$03 demon-13
Demon - frame 3 - tile 2
A7CE DEFB $F5 Horizontal (X axis) pixel offset (-11 pixels)
A7CF DEFB $ED Vertical (Y axis) pixel offset (-19 pixels)
A7D0 DEFB $27 Graphic consists of 39 bytes
A7D1 DEFB $40,$20,$30,$30,$28,$29,$29,$75 demon-14
A7D9 DEFB $F4,$F6,$E6,$16,$F6,$F7,$FB,$7B
A7E1 DEFB $7B,$7D,$7D,$7A,$76,$8E,$7E,$3F
A7E9 DEFB $1F,$0F,$07,$0B,$0B,$09,$09,$05
A7F1 DEFB $05,$05,$05,$05,$09,$09,$09
Demon - frame 3 - tile 3
A7F8 DEFB $FD Horizontal (X axis) pixel offset (-3 pixels)
A7F9 DEFB $F2 Vertical (Y axis) pixel offset (-14 pixels)
A7FA DEFB $22 Graphic consists of 34 bytes
A7FB DEFB $01,$39,$FF,$EE,$00,$C6,$EE,$00 demon-15
A803 DEFB $01,$01,$45,$7D,$FF,$7D,$6D,$92
A80B DEFB $EE,$92,$ED,$65,$FF,$FD,$BD,$BD
A813 DEFB $D5,$D5,$D5,$95,$25,$AD,$8E,$16
A81B DEFB $26,$26
Demon - frame 3 - tile 4
A81D DEFB $05 Horizontal (X axis) pixel offset (+5 pixels)
A81E DEFB $ED Vertical (Y axis) pixel offset (-19 pixels)
A81F DEFB $27 Graphic consists of 39 bytes
A820 DEFB $04,$08,$08,$08,$18,$18,$38,$2C demon-16
A828 DEFB $6C,$FC,$C6,$BB,$BC,$BC,$B8,$B8
A830 DEFB $B8,$B8,$78,$B8,$C8,$FC,$F0,$E0
A838 DEFB $E0,$C0,$80,$80,$00,$00,$00,$C0
A840 DEFB $40,$40,$40,$40,$40,$80,$80
